Technical Specifications

Operating Band
LTE FDD Cat M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85

GNSS Chipset：MediaTek high gain GNSS receiver
Parallel GNSS：GPS+Glonass or GPS+Beidou
Receiver Type：33 tracking / 99 acquisitions- channel GNSS receiver
Position Accuracy (CEP)：Autonomous < 2.5m
T

Connector：OBDII
SIM card slot：Nano SIM card slot
LTE/GNSS/Bluetooth Antenna：Internal only
Indicator LED：Network and GNSS
FOTA：Yes
BLE (Bluetooth Low Energy)：4.0
USB：Debug
Buzzer: Event triggeri

Dimensions：63mm*47mm*20mm (2.48” *1.85” *0.79”)
Weight：45g (1.58oz)
Backup Battery：Li-Polymer 200 mAh/ 3.7V
Operating Voltage：7V to 32V DC
Operating Temperature：-30℃ ~ +80℃ (-22°F ~ 176°F)
Storag

Transmit Protocol：TCP, UDP, MQTT, SMS
BLE Accessory Support：Yes
Scheduled Timing/angle/distance Report：Report position and status at preset intervals
External Power Status Alarm：Report when externa

FCC, PTCRB, CE, RCM, AT&T, US Cellular
*Verizon(pending), T-mobile (pending), Sprint (pending)
