Technical Specifications

CAT-M1: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85
CAT NB2: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85
GSM/GPRS: 850/900/1800/1900MHz

GNSS Chipset：MediaTek High Gain GNSS receiver
Parallel GNSS：GPS+Glonass+Galileo+Beidou
Receiver Type：33 tracking / 99 acquisitions- channel GNSS receiver
Position Accuracy (CEP)：Autonomous < 2m
St

Digital Input：1
Digital Output：1
Indicator LED：Network and GNSS
FOTA：Yex
BLE (Bluetooth Low Energy)：5.0

Waterproof：IP65
Dimensions：102.5mm*42.5mm*12mm (4.04” *1.67” *0.47”)
Weight：55g (1.94oz)
Backup Battery：Li-Polymer 200 mAh/ 3.7V
Operating Voltage：7V to 60V DC
Operating Temperature：-30℃ ~ +80℃ (

Transmit Protocol：TCP, UDP, MQTT, SMS
BLE Accessory Support：Yes
Scheduled Timing/angle/distance Report：Report position and status at preset intervals
External Power Status Alarm：Report when externa

CE
FCC
PTCRB
AT&T
T-Mobile
