Technical Specifications

FDD: B1/B2/B3/B4/B5/B/8/B12/B13/B18/B19/B20/B25/B28
TDD: B39 (Cat M1 only)
EGPRS 850/900/1800/1900MHz

GNSS Chipset：Qualcomm Gen 8C GNSS receiver
Parallel GNSS：GPS+Glonass+Galileo+Beidou
Receiver Type：33 tracking / 99 acquisitions- channel GNSS receiver
Position Accuracy (CEP)：Autonomous < 2m
Stand

Digital Input: 3
Digital Output：2
Configurable Input (Digital/Analog)：3
Indicator LED：Network and GNSS
FOTA：Yes
BLE (Bluetooth Low Energy)：5.0

Waterproof：IP65
Dimensions：102.5mm*42.5mm*12mm (4.04” *1.67” *0.47”)
Weight：55g (1.94oz)
Backup Battery：Li-Polymer 200 mAh/ 3.7V
Operating Voltage：7V to 60V DC
Operating Temperature：-30℃ ~ +80℃ (

Transmit Protocol：TCP, UDP, MQTT, SMS
BLE Accessory Support：Yes
Scheduled Timing/angle/distance Report：Report position and status at preset intervals
External Power Status Alarm：Report when externa

CE
FCC
PTCRB
AT&T
Verizon
